Visonic POWERMASTER-10 - INSTALLER GUIDE - Configuring the Jamming Detection; Configuring Whether a Missing Device Causes the System to Become NOT READY

D-302756 47
You can now press the or button to program any other
menu in " DEFINE PANEL " or press the button to take you to " <OK>
TO EXIT ".
4.8.9 Configuring the Jamming Detection
Here you determine whether jamming (interfering transmissions, on the radio channel used by the system) will
be detected and reported or not.
If a jam detection option is selected, the system does not allow arming under the relevant jamming conditions.
Jam Detection Options
Option Detection and Reporting when
UL 20/20
(USA standard)
There is continuous 20 seconds of jamming
EN 30/60
(Europe standard)
There is an accumulated 30 seconds of jamming within 60 sec.
class 6 (30/60)
(British standard)
Like EN (30/60) but the event will be reported only if the jamming
duration exceeds 5 minutes.
Disable (default) (No jamming detection and reporting).
To Configure the Jamming Detection
1.
Repeat steps 1 to 4 of section 4.2 "Entering the Installer Menu".
2.
3.
or
4.
5.
or
Select between "UL 20/20", "EN 30/60", "class 6 (30/60)" and
"disable".
6.
You can now press the or button to program any other
menu in " DEFINE PANEL " or press the button to take you to " <OK>
TO EXIT ".
4.8.10 Configuring Whether a Missing Device Causes the System to Become
"NOT READY"
Here you determine if the system will be in NOT READY status when there is a supervision failure. In the "in
supervision" mode, the system will be in NOT READY status if during the last 20 minutes a supervision
message was not received. Options: normal (default) and in supervision.
Note: To comply with EN requirements, "in supervision" must be selected.
19:JAM DETECT
disable

19:JAM DETECT
01:ENTRY DELAY 1
DEFINE PANEL
