D-302756 5
Data Retrieval
Alarm memory, trouble, event log
Real Time Clock (RTC)
The control panel keeps and displays time and date. This feature is also used
for the log file by providing the date and time of each event
Compliance with U.S.
Standards:
USA: (FCC) CFR 47part 15 and part 68
Canada: RSS 210
Compliance with European CE
Standards
The PowerMaster-10 is compatible with the RTTE requirements - Directive
1999/5/EC of the European Parliament and of the Council of 9 March 1999.
According to the European standard EN50131-1, the PowerMaster-10
security grading is 2 – "low to medium risk" and environmental classification
is II – "indoor general" and the power supply type is A.
GSM standards
Europe: Complies with CE standards 3GPP TS 51.010-1, EN 301 511,
EN301489-7
USA: CFR 47 Part 22 (GSM850) and Part 24 (GSM 1900).
EMC standard: CFR 47 Part 15.
2.2 Wireless
Frequency Band (MHz)
Europe: 433, 868, USA: 915.
Antenna Type
Spatial diversity
Encryption
AES-128
Protocol
PowerG
2.3 Electrical
External AC/AC adapter Europe: 230VAC 50Hz input, 9VAC 700mA output.
USA: 120VAC 60Hz input, 9VAC 1000mA output.
Current Drain Approx. 70 mA standby, 1600 mA peak at full load.
Minimum battery voltage
4.8V
Note: For CE compliance the battery backup period shall exceed 12 hours.
Backup Battery Pack
4.8V 1300 mAh, rechargeable NiMH battery pack, p/n GP130AAM4YMX,
manufactured by GP or equivalent
Note: For compliance with UL standards the battery backup period shall
exceed 24 hours.
Backup Battery Pack
4.8V 2200 mAh, rechargeable NiMH battery pack, p/n GP230AAHC4YMX,
manufactured by GP
Battery Test
Once every 10 seconds
2.4 Communication
Built-in Modem
300 baud, Bell 103 protocol
Data Transfer to Local
Computer
Via RS232 serial port
Report Destinations
2 Monitoring Stations, 4 private telephones
Reporting Format Options
SIA, Pulse 4/2 1900/1400 Hz, Pulse 4/2 1800/2300 Hz, Contact ID,
Scancom.
Pulse Rate
10, 20, 33 and 40 pps - programmable
Message to Private Phones
Tone
