D-302756 65
Note: "Zxx" indicates the type of device and device number that is being
tested. "NNN" indicates the number of devices that have not yet been
tested.
At this stage if any key is pressed the PowerMaster-10 display will read
"
<NEXT> TO END
" alternating with "
<OK> TO CONTINUE
". Press the
button to stop the current test and jump to the next test, or,
press the button to continue the test, or, press the
button to exit.
At the end of the testing procedure the PowerMaster-10 display will read
"
SHOW ALL DEVICES
".
∗ If there are no wireless devices enrolled in the PowerMaster-10
system, the PowerMaster-10 display reads "
NO DEVICES
".
Pressing the or buttons at any stage in the procedure
will take you to "
<NEXT> TO END
" or “
<OK> TO EXIT
”.
5.1.2 Testing One Device
1.
Repeat steps 1 to 4 of section 4.2 "Entering the Installer Menu".
2.
3.
4.
5.
6.
or
Select between "CONTACT SENSORS", "MOTION SENSORS", "SMOKE
SENSORS", "KEYFOBS", "SIRENS" or "REPEATERS", for example, "MOTION
SENSORS".
7.
The PowerMaster-10 display will read the device name alternating with
the location.
8.
The PowerMaster-10 display will read "TESTING Zxx 001" or
"ACTIVATE NOW Uxx" for keyfobs.
or
ACTIVATE NOW Uxx
Front door
Zxx:Motion Sens
MOTION SENSORS
CONTACT SENSORS
TEST ONE DEVICE
Z01 NOW: STRONG
TESTING Zxx 001
TEST ALL DEVICES
WL DEVICES
DIAGNOSTICS
