72 D-302756
Fault What it means Solution
SIREN AC
FAILURE
There is no power to the siren Make sure that the AC power supply is
connected properly
AC FAILURE There is no power to gas sensor Make sure that the AC power supply is
connected properly
GSM NET FAIL The GSM communicator is not able to
connect to the cellular network.
i) Move the Panel and GSM unit to
another location.
ii) Enter and exit the installer menu
iii) Disconnect GSM unit and install it again
iv) Replace SIM card
v) Replace the GSM unit
RSSI LOW The GSM communicator has detected that
GSM network signal is weak
Move the Panel and GSM unit to another
location.
AC SUPPLY
FAILURE
There is no power and the system is working
on backup battery power
Make sure that the AC power supply is
connected properly
COMM. FAILURE A message could not be sent to the
monitoring station or to a private telephone
(or a message was sent but was not
acknowledged)
i) Check telephone cable connection
ii) Check that correct telephone number
has been dialed.
iii) Dial Monitoring Station to check
whether or not events are received.
CPU LOW
BATTERY
The backup battery within the control panel
is weak and must be replaced (see
Chapter 7 - Replacing Backup Battery).
i) Check for AC power is available in the
Panel.
ii) If trouble exists for more than 72 hours,
replace the battery pack
CPU TAMPER The control panel was physically tampered
with or its cover was opened, or it was
removed from wall.
The control panel is not closed properly.
Open the control panel and then close it.
FUSE TROUBLE The PGM fuse is burnt out or overloaded. Make sure that the connection load
conforms to that specified in the
Specifications.
LINE FAILURE There is a problem with the telephone line i) Lift the telephone receiver and make
sure a telephone line can be heard
ii) Check the telephone connection to the
control panel
7.2 Dismounting the Control Panel
A. Remove the screw that fastens the front unit to the back unit (see Figure 3.3).
B. Remove the 4 screws that fasten the back unit to the mounting surface (see Figure 3.3) and remove the
control panel.
7.3 Replacing the Backup Battery
Replacement and first-time insertion of battery pack is similar (see Figure 3.1).
With fresh battery pack, correct insertion and tightened battery compartment lid, the TROUBLE indicator should
extinguish. However, the “MEMORY” message will now blink in the display (caused by the “tamper” alarm you
triggered when opening the battery compartment lid). Clear it by arming the system and immediately disarming.
7.4 Fuse Replacement
The PowerMaster-10 has an internal fuse that has automatic reset. Therefore, there is no need to replace the
fuse.
When over current condition occurs, the fuse cuts off the circuit current. Upon fault current being removed for
several seconds, the fuse is automatically reset and allows current flow through the circuit again.
