105
Prima Sprint.
P_01152
OPERATING MANUAL
VERSION 07/2009
ORDER NUMBER DOC 2305835
6/5 1.3 m 2302060 Hose, red ∅ 8 mm
6/6 1 935974 Coupling plug with anti-kink spring
6/7 5 9998069 Velcro fastener
7 1 2308067 Piston vibrator, light
8 1 2304102 Transition piece
9 2308062 Powder hose set ∅ 9x5000 mm; 0.35x196.85 inches
10 1 130215 Grounding cable 10 m; 32.81 ft
11 1 241270 Mains cable
10.6 SPARE PARTS LIST OF THE TROLLEY
1
3
2
Item K Quantity Order No. Description
1 1 2307117 Injector bracket (complete)
2 1 2303279 Guide bush
3 1 2305421 Nut
4 2 2305431 Adjustment foot
◆ Wearing part
● Not part of the standard equipment but available as a special accessory.
★ only available as a set
4
