P_00889
OPERATING MANUAL
VERSION 07/2009 ORDER NUMBER DOC 2305835
10.19 HICOAT-ED PUMP-F
Item K
Quantity Order No. Description
241624 HiCoat-ED Pump-F
1
◆
1 241229 Low air collector nozzle
2 1 241479 Hose sleeve
3 1 241466 Outer nut
4 1 241930 Injector nozzle
5 2 241460 Spring check valve
7 1 9970149 Sealing ring
8 1 9992709 Quick-release plug
9 1 9992710 Quick-release socket
10 1 9970150 Sealing ring
11
◆
2 9974023 Sealing ring, electrically conductive
◆ Wearing part
● Not part of the standard equipment but available as a special accessory.
★ only available as a set
