Page #116 background image
116
Prima Sprint.
8
10
5
4
11
9
5
7
1
2
3
P_00894
OPERATING MANUAL
VERSION 07/2009 ORDER NUMBER DOC 2305835
10.18 PI-F1 POWDER INJECTOR
Item K
Quantity Order No. Description
241622 PI-F1 powder injector
1
◆
1 241225 Clearance collector nozzle
2 1 241476 Conductive nozzle
3 1 241466 Outer nut
4
◆
1 241923 Injector nozzle
5 2 241460 Spring check valve
7 1 9970149 Sealing ring
8 1 9992709 Quick-release plug
9 1 9992710 Quick-release socket
10 1 9970150 Sealing ring
11
◆
2 9974023 Sealing ring, electrically conductive
◆ Wearing part
