WAGNER Prima Sprint Airfluid User Manual

98
Prima Sprint.
P_01130
OPERATING MANUAL
VERSION 07/2009
ORDER NUMBER DOC 2305835
Item K Quantity Order No. Description
2306090 Prima Sprint Airfl uid C manual system (Standard edition)
2307069 Prima Sprint Airfl uid C manual system (USA edition)
2307070 Prima Sprint Airfl uid C manual system (Japanese edition)
1 1 2303258 Airfl uid trolley
2 1 2305109 EPG Sprint control unit
9951117 Thermal delay fuse 1A (included in EPG Sprint)
2 1 2305127 EPG Sprint control unit (USA edition)
9951117 Thermal delay fuse 1A (included in EPG Sprint)
3 1 241622 PI-F1 powder injector
4 1 265281 ST 550/10 suction tube
5 1 2305069 PEM-C4-Ergo manual gun
1 2305070 PEM-C4-Ergo FM manual gun (USA edition)
6 2306401 Prima Sprint connection parts
6/1 1 2303714 Sealing coupling with anti-kink spring
6/2 1.3 m 9982079 Hose, black ∅ 6 mm
6/3 1.3 m 700370 Hose, blue ∅ 8 mm
6/4 1 935973 Sealing coupling with anti-kink spring
6/5 1.3 m 2302060 Hose, red ∅ 8 mm
6/6 1 935974 Coupling plug with anti-kink spring
10.2 SCOPE OF DELIVERY AND SPARE PARTS LIST OF PRIMA SPRINT AIRFLUID
MANUAL POWDER SYSTEM
3
4
5
2
6
8
1
7
