WAGNER Prima Sprint Airfluid User Manual

122
Prima Sprint.
2x
kV
90
80
70
60
50
40
30
20
10
100
Tribo Corona
5
4
3
2
1
120
100
80
60
40
30
20
15
10
5
0
10
20
30
40
50
60
70
80
90
100
%
Ø
12
10
11
9
8
m /h
5.0
4.0
3.0
2.0
6.0
m /h
4.0
3.0
2.0
1.0
0.5
0.4
0.3
0.2
0.1
1.5
33
μA μA
5.5
4.5
3.5
2.5
2.2
P_01182
EPGSPRINT
OPERATING MANUAL
VERSION 07/2009
ORDER NUMBER DOC 2305835
BRIEF DESCRIPTION
1 OPERATING ELEMENTS
9
10
11
12
13
8 7 6 5 4 3
1
2
1 Button: Standby (for switching into stand-by mode)
2 Rotary controller (for selecting programs and parameters)
3 Selection button: Atomizing air/Tribo air [m³/h]
4 Selection button: Powder quantity [%]
5 Selection button: Overall air quantity [m³/h]
6 Selection button: Characteristic slope
7 Selection button: Current limiting [µA]
8 Selection button: High-voltage [kV]
9 Program button: Surface parts (coating surface parts)
10 Program button: Second-coating
11 Program button: Profi le parts (coating profi le parts)
12 Program button: Double click (for rapid program changes without interrupting the coating
process, by simply double-clicking on the gun trigger)
13 Program button: Additional programs 5-50
14 Display LED: Fault
15 Button: Rinse (for quick and easy cleaning of components carrying powder)
15
14
Programs Electrostatic
parameters
Air
parameters
Selection/display
elements
