42
Prima Sprint.
OPERATING MANUAL
VERSION 07/2009 ORDER NUMBER DOC 2305835
6.3.1 FACTORY SETTINGS FOR PROGRAMS NO. 1-4
The following set values are stored in program nos. 1-4 in the factory.
Program
No.
Designation Characteristics High-voltage
[kV]
Current limiting
[µA]
Characteristic Overall air
[m³/h]
Feed air
[%]
Atomizing air
[m³/h]
P01
Flat
workpiece
High gun
performance
90 80 standard 4.0 70 0.1
P02
Second-
coating
Avoidance of
spraying back
50 20 soft 3.6 57 0.1
P03 Profi lteil
Penetration and
reduced
build-up of
edges
70 40 soft 3.6 50 0.1
P04 Double click Small parts 80 20 soft 3.6 45 0.1
P05-50 variable individual 80 100 standard 4.5 80 0.1
Hint:
Under normal conditions, metallic powder can be processed well using program nos.1-4.
When operating the system with a Tribo gun, the values for overall air, powder fl ow and Tribo air must be adjusted accordingly and saved.
With the 3l container variant, the values must also be adjusted individually and saved.
