Prima Sprint.
OPERATING MANUAL
VERSION 07/2009
ORDER NUMBER DOC 2305835
Dimensions:
Height 1120 mm; 44.10 inches
Width 595 mm; 23.43 inches
Depth 740 mm; 29.13 inches
Weight approx. 38 kg; 83.77 lbs
Max. box size 420x420x400 mm; 16.54x16.54x15.75 inches
Max. fi lling weight of box 30 kg; 66.14 lbs
Electrical:
Mains (AC) 85 VAC-250 VAC
Frequency 47 Hz-440 Hz
Maximum power 40 W
Output voltage max. 22 Vpp
Output current max. 0.9 A
Corona current limitation 5 µA-120 µA (adjustable)
Tribo current limitation higher than 12 µA
(ATEX: switch the unit off)
Protection class IP 64
Pneumatic:
Compressed air connection G1/4"
Connection hose diameter 18.5 x 12.5 mm
Pressure range input air 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air quantity max. 20 m³/h; 706.2 cf/h
Sum of feed and dosage air 2-12 m³/h; 70.6-423.7 cf/h
Gun air 0.05-4.5 m³/h; 1.765-158.9 cf/h
Wagner injector type PI-F1, HiCoat ED-Pump F
Compressed air quality
as per ISO 8573.1
3.5.2
4.4 TECHNICAL DATA
SIHI_05034_ENG
WARNING
Outgoing air containing oil!
Risk of poisoning if inhaled
Provide water-free and oil-free compressed air (quality standard
3.5.2 as per ISO 8573.1) 3.5.2 = 5 μm / +7°C; 44.6°F / 5mg/m³.
