6.5.7 DISPLAYING ACTUAL VALUE OF CURRENT LIMITING
Procedure:
1. Press “current limitation“ button 29
for around 2 seconds. Yellow LED 30
fl ashes quickly.
The actual current limitation value is
shown in display 19.
2. LED display 19 jumps to the function
value now selected by pressing a
selection button or turning rotary
controller 24.
Press “current limitation“ button 29 for around 2 seconds. Yellow LED 30 fl ashes quickly.
19
24
29
30
