77
Prima Sprint.
P_00926
6
5
7
8
6
10
9
6
P_01100
OPERATING MANUAL
VERSION 07/2009 ORDER NUMBER DOC 2305835
5. Locate gun extension 6 onto the gun housing 5 and tighten the outer nut 7.
6. Depending on the planned usage, either locate defl ector cone 8 or atomizer sleeve 9
and fan spray nozzle 10 carefully on the gun extension 6.
The spray gun is ready for use again.
