Replacing the IonSABRE APCI probe sample capillary 5-65
5. Remove the PEEK union/UNF coupling assembly, and capillary from
the probe.
6. Grip the PEEK union with the 8-mm wrench and use the 7-mm wrench
to loosen the locknut.
PEEK union/UNF assembly
Capillary
PEEK union
7-mm wrench
Locknut
UNF coupling
8-mm wrench
