Electrical and handling symbols A-11
Electrical and handling symbols
Electrical symbols
These can appear in instrument user manuals and on the instrument’s front
or rear panels.
Electrical power on
Electrical power off
Standby
Direct current
Alternating current
Protective conductor terminal
Frame, or chassis, terminal
Fuse
Recycle symbol: Do not dispose in municipal waste.
