Waters TQ Detector User Manual

4-6 Optional APCI Mode of Operation
7. Connect the IonSABRE APCI probe’s electrical lead to the instrument’s
probe connection.
8. Using tubing of the appropriate internal diameter (ID), connect the
fluidics system’s diverter valve to the IonSABRE APCI probe.
Tip: Two tubes of differing ID are supplied with the instrument.
Requirement: If you are replacing the tubing supplied with the
instrument, minimize the length of the tube connecting the diverter
valve to the IonSABRE APCI probe. Doing so minimizes delays and
dispersion.
9. Close the instrument’s access door.
Installing the corona pin
To install the corona pin
Refer to “Installing the corona pin” on page 3-6.
Removing the corona pin
To remove the corona pin
Refer to “Removing the corona pin” on page 3-8.
Warning: To avoid electric shock, do not use stainless steel
tubing to connect the diverter valve to the IonSABRE APCI
probe; use the PEEK™ tubing supplied with the instrument.
