Waters TQ Detector User Manual

Replacing the APCI probe heater 5-73
3. Dispose of the probe heater in accordance with local environmental
regulations.
4. Carefully slide the replacement probe heater over the capillary sleeve on
the probe assembly
5. Fit the probe heater to the probe assembly, ensuring that the heater is
fully seated on the probe assembly.
6. Fit the probe to the instrument (see “Installing the IonSABRE APCI
probe” on page 4-3).
Warning: The probe heater can be contaminated with
biohazardous and/or toxic materials. Dispose of it according
to local environmental regulations.
Caution: To avoid damaging the probe heater’s electrical
connections, do not twist the heater when fitting it to the probe
assembly.
Probe heater connections
Capillary sleeve
Capillary
