2.1 Operator’s manual
10
Operator’s Manual | 4080T Basic Line | 1000408123 | 05/2019 | [en]
2.1.2
Storing the operator’s manual
Fig.1: Storage location for the oper-
ator’s manual
The operator’s manual and any supplements are part of the vehicle and
must be available to the operator at all times. The vehicle is equipped
with a storage location for the operator’s manual.
The storage location is a position A in the cab.
2.1.3
Understanding these instructions
This section helps to understand the operator’s manual and the illustra-
tions used therein.
Target group
On the one hand, this operator’s manual is intended for the operating per-
sonnel of the vehicle. It describes the operating activities that must be
read in order to operate the vehicle safely and efficiently.
On the other hand, this operator’s manual is intended for the operating
company of the vehicle. It provides him with the necessary information to
ensure safe working conditions for the personnel deployed and, if neces-
sary, to take measures to protect the operating personnel.
This operator’s manual is also intended for the maintenance personnel of
the vehicle. Only maintenance work that may be carried out by the oper-
ator is described. Work that is not described must not be carried out. For
all other activities, contact the service partner or an authorized service
center.
Explanation of symbols
Symbol Explanation
1., 2., 3… Indicates an activity. The sequence of the steps must be observed.
⇨ Indicates a result or an intermediate result of an action.
✓ Indicates prerequisites that must be established for the activity.
● Indicates a list, e.g. if several components are named one after the other.
- Indicates a sub-list, e.g. if components consist of further components
Identifies a position, usually a component or control element, in a graphic. The numbering
may be sequential or in Roman numerals.
1; A Indicates the naming of components in explanatory texts. It is identical with the adjacent po-
sitions in the illustrations.
Indicates a direction of movement or different positions for switches.
► Indicates the avoidance of hazards in warning notices.
[▸52] Indicates a cross-reference in tables. Here e.g. reference to page 52
