Operation
Working with attachments 7.12
159
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
Fig.157: Adjusting the forks
1. Lift the attachment.
ð Recommended height is approx. 10 to 30 cm.
2. Move the forks to position1 .
ð Locking is released.
3. Push the forks into the required position.
ð Handle forks only as shown in position 2.
4. Move the forks to position3.
5. Move the forks until the lock engages.
ð Handle forks only as shown in position 2.
ð The lock is engaged.
ð Distance is set.
WARNING
Risk of injury from falling load when the loader unit is raised!
Falling load (e.g. large bales or bale stacks) can lead to serious injury or
death.
► Never lift or transport several large bales or crates at the same time.
► The stacking of general cargo with vehicles without a driver's protect-
ive roof or cab is prohibited.
► Do not step under the raised loader unit.
► Do not tilt the attachment up to the stop when the loader unit is
raised.
