Transportation
Towing the vehicle 8.1
163
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
Fig.160: Position of the variable dis-
placement pump
Getting ready for towing
1. Apply the parking brake.
2. Switch off the ignition and remove the starting key.
3. Open the engine cover.
4. Raising the cab sideways: see Cab on page 180
ð The variable displacement pump 1 becomes accessible.
NOTICE
Risk of damaging the hydraulic system!
► Do not screw in the threaded bolts any further than described, other-
wise important parts of the valves of the variable displacement pump
are destroyed.
► After towing, unscrew the threaded bolts again as far as the stop and
secure them with the hexagon nuts. Otherwise vehicle operation is
not possible!
8
