Transportation
8.2 Loading the vehicle
168
Operator’s Manual | 4080T Basic Line | 1000408123 | 05/2019 | [en]
8.2.2
Loading the vehicle
Fig.164: Loading vehicle
The prerequisites for loading are listed in the following:
• Secure the transport vehicle with wheel chocks to prevent it from
rolling away.
• Place the access ramps at the smallest possible angle.
– Do not exceed the maximum slope.
– Use access ramps only with an anti-skid surface.
• Ensure that the loading surface is clear and access to it is not ob-
structed, e.g. by superstructures.
• Ensure that the access ramps and the wheels of the vehicle are free
of snow, ice, oil or grease.
• Check the oil level of the engine.
– The oil level must be visible at the max. mark on the oil dipstick.
Prepare for loading
1. Start the engine of the vehicle.
2. Retract the telescopic boom.
3. Lift the loader unit so that it is not possible to touch the ramps with
the attachment.
4. Ensure that the attachment is securely locked.
