Maintenance
Checking fill levels 9.6
191
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
NOTICE
Technical damage due to insufficient filling level!
► Check or refill the filling level according to the service intervals spe-
cified in these operating instructions.
► Add the coolant when the symbol
appears on the display
between service intervals.
Fig.183: Fill opening for cooling li-
quid
If the coolant level is below the MIN mark, the coolant must be refilled at
the fill opening 1.
ü Preparations for maintenance in the engine compartment were car-
ried out.
ü Protective equipment is on.
1. Open the lid of the fill opening for coolant.
2. Add coolant.
3. If necessary, add coolant until the MAX mark is reached.
4. Close fill opening for coolant.
Environment
Possible environmental damage.
► Avoid release of antifreeze compound coolant.
► Collect antifreeze compound and coolant and dispose of in an envir-
onmentally friendly manner.
9.6.4.3 Checking the antifreeze compound
Fig.184: Check the antifreeze com-
pound
The antifreeze compound prevents the coolant from freezing at sub-zero
temperatures and protects the engine block and radiator from internal
corrosion. Under normal conditions an antifreeze compound content of
-20 °C to -30 °C is sufficient. The antifreeze concentration can be
checked with an antifreeze tester.
Coolant compound table
Outside temperature
1)
Water content Antifreeze compound
2)
-37°C 50% 50%
1) Use the 1:1 concentration for warm outside temperatures, too, to en-
sure protection against corrosion, cavitation, and deposits.
2) Do not mix the coolant with other coolants.
9
