Maintenance
Cleaning and maintaining vehicle 9.8
203
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
Fig.198: Remove safety filter
1 Cover of the housing
2 Main filter
3 Safety filter
4 Housing
Remove safety filter
ü Preparations for maintenance in the engine compartment were car-
ried out.
1. Remove the fasteners on the cover.
2. Remove the cover.
3. Pull out oil main filter.
ð The safety filter can be seen now.
4. Pull out the safety filter.
5. Install a new safety filter.
Installing the safety filter
The air filter is assembled in reverse order. Make sure that the air filter is
firmly seated in the housing. If the main filter is difficult to install, the
safety filter is not correctly seated in the housing. The main filter may be
damaged.
1. Insert safety filter.
2. Insert the main filter into the housing.
3. Do not force the main filter into place.
4. Reapply cover. The dust valve must be pointing downwards.
5. Fasten the lid with fasteners.
9.8.2.5
Check air intake line
Check air intake hose between air filter and engine:
• The hose must not be porous, cracked or damaged.
• The hose must sit firmly on the connection piece, it must not slip from
the connection pieces. The fastening clamps must be tightened
firmly.
9
