blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Definition of residual
airgap for keep rails /
extension keep rails:
distance between keep
rail or extension keep
rail and upper edge
of STV faceplate for
PVC-U / aluminium
Residual airgap Explanation
   mm Magnetic clip + keep rail not possible (may be
possible without keep rail/with single keep
and single magnetic clip)
  -  mm T-Magnetclip 1,5 EAV4+/BM+ GR,
6 mm triggering range
  mm Magnetic clip not possible  magnet no
longer releases because the airgap is too
large
Definition of residual
airgap: Example of wood,
4 mm airgap
Residual airgap Explanation
Wood  mm airgap
Wood  mm airgap
T-MAGNETCLIP 1,5 EAV4+/BM+ SB U24X7,5 GR,
incl. cover cap for milling radius
Wood  mm
T-MAGNETCLIP 1,5 EAV4+/BM+ SB U24X7,5 GR
Wood flush mm residual
airgap  single keep
T-MAGNETCLIP 1,5 EAV4+/BM+ SB U24X7,5 GR,
incl. cover cap for milling radius
Use of magnetic clip for keep rails/extension keep rails
Use of magnetic clip for wooden profiles
