blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Connection of motor
housing to radio
receiver ENTRAsys+
RX (plug-in)
Connection from
radio receiver
ENTRAsys+ RX
to the fingerprint
ENTRAsys+ FD
(plug-in)
Figure 3.6.2-6: Wiring blueMatic EAV4 / EAV4+ with "Fingerprint SOMMER
ENTRAsys+" (sash side)
Assembly -wire blue
motor housing plug
-wire white plug for
access control 
white  V DC
brown V Masse
green external opening signal
yellow not used
grey
pink
green  external opening signal (unlock)
greypink  only with EAV otherwise
not used potential-free
signal output various
signals adjustable
• Default  door closed 
locked
• alternatively signal for
swing door opener
Notice! max  m extendable
(min  x  mm)
}
EAV
potential-free
signal-output
Attention!
Remove jumpers
(without a jumper,
the output is
potential-free)
