Figure 3.6.3-1: Wiring blueMatic EAV4 / EAV4+ with tappet contact and
"Fingerprint ekey dLine" (sash side)
white  V DC
brown V
green external opening signal
yellow (not used)
grey (not used)
pink (not used)
greenwhite  input for external
potential-free contact
(eg unlocking via
intercomopen button)
Notice! max  m extendable
(min  mm

)
Attention!
Remove jumpers
(without a jumper, the
output is potential-free)
Assembly -wire blue
motor housing plug
-wire white plug for
access control 
 white VDC ()
 brown GND (-)
 green Opening signal
 yellow Opening signal
Connection to the ekey dLine control unit
(ekey plug and cable)
