blueMatic EAV4 / EAV4+ Installation, Operating and
Maintenance Instructions
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Figure 3.6.3-2: Wiring blueMatic EAV4 / EAV4+ with tappet contact and
"Fingerprint ekey dLine and frame power supply" (sash side)
white  V DC
brown V
green external opening signal
yellow (not used)
grey (not used)
pink (not used)
greenwhite  input for external
potential-free contact
(eg unlocking via
intercomopen button)
Notice! max  m extendable
(min  mm

)
Attention!
Remove jumpers
(without a jumper, the
output is potential-free)
230V AC
Notice: The positioning of
frame power supply and
cable transition on the hinge
side is recommended, either
between lower / middle door
hinge or in each case approx.
10 cm above / below the
middle door hinge.
 white VDC ()
 brown GND (-)
 green Opening signal
 yellow Opening signal
Connection to the ekey dLine control unit
(ekey plug and cable)
