Otherwise, the first word of the
next
lOCO
is
fetched and
loaded as described above, and the second word is fetched
and loaded as described below.
Since the Transfer in Channel command permits lOCOs to
be fetched
from
nonconsecutive locations, lOCOs
contain-
ing Transfer in Channel commands may be included within
a command list
either
to
achieve
command list
continuity
from
one segment
of
a command list to
another
segment or
to c?nstruct
reiterative
loops.
For
all
lOCOs,
except
a control lOCO containing a Trans-
fer in Channel command, the lOP will
automatically
access
main memory
at
the
appropriate time, as determined by
the
priority
that
prevails for accessing main memory, and fetch
the
second word of
the
lOCO from
the
next
consecutive
ascending (odd) memory word location of
the
command list
and increment the command address register by
one.
Thus,
in
all
cases,
after
a fetching operation
is
completed, the
content
of
the command address register
wi
II
be an even
(or doubleword) address.
The
contents
of
the second word are stored in appropriate
registers within the
I/O
subchannel. Depending upon the
I/o
order, as described under IIExecution Phase
ll
, the
con-
tents of the various fields are
either
used or ignored.
In
addition to the
lOP
Control Error (IOPCE), the following
types
of
lIunusual end
ll
conditions may be
detected
during
the fetching phase
of
an
I/O
operation: Memory Address
Error
(MAE),
Control Check Fault (CCF),
lOP
Memory Error
(IOPME),
Bus
Check
Fault (BCF), and Memory Interface
Error (MIE).
The
detection
of any of these errors causes
the
I/O
operation to be terminated and
if
the
IUE
flag is set
to
a 1,
an
"unusual end" interrupt is requested.
EXECUTION
PHASE
Although
the
services of the
BP
are
not required during
this phase, the
BP
may
at
any time
execute
either
a TIO,
TDV,
or POL instruction without interfering with the
I/o
operation. However, excessive testing may cause a
data
overrun condition. The
BP
may also
execute
either
an
HIO or
P.IO
instruction and stop the
I/o
operation. After
the second word
of
an lOCO is fetched and providing
no
lIunusual end
ll
condition was
detected,
the lOCO
is
executed
as prescribed by the parameters contained therein.
As
a
function
of
the order and the status
of
the Skip flag,
if
applicable,
an lOCO
may
be
executed
in one
of
five ways,
as described below:
1.
Certain
Control orders (e.
g.,
Stop) may be
executed
by the
device
whi
Ie
the lOP monitors the operation in
accordance
with the
applicable
control flags. Since
no
memory accesses and
data
(or information) transfers
occur, the contents of the memory byte address
reg-
ister, write key register, and byte count register may
be ignored.
Other
Control orders (e.
g.,
Rewind for a
magnetic
tape
unit) are listed and described in
applic-
able
Xerox peripheral equipment reference manuals.
Depending upon the control function performed,
certain
Control orders may be a part
of
an
I/o
operation
which may be continued
after
the Control order is
executed.
For
example, an
I/o
operation involving
a magnetic
tape
unit may contain a Rewind order to
reposition
the
tape
prior to reading (or writing) one or
more records.
Note:
Within the
context
of
the above
explanation,
the Control order is defined to be one
that
does not transfer
any
information; thus,
data
chaining
is precluded within the lOCO
con-
taining the Control order; however, command
chaining may be
specified.
Control orders
that
involve information transfers when
executed
are
described below (see paragraphs 2 and 4).
2. If the order specifies an input operation (e.
g.,
Read,
Read
Backward,
or
Sense) and the Skip flag is coded
as a
0,
all parameters
of
the
current lOCO may be
applicable.
As
a result
of
receiving an appropriate
input
order, the devi
ce
transmits
data
(Read, or Read
Backward order) or information
from
special registers
(Sense order) into
data
buffers
of
the
associated
I/O
subchannel within the lOP.
Depending upon the priority
that
prevai
Is
for accessing
main memory, the lOP accesses a memory word location
(as specified by the current memory byte address),
transfers up to four bytes
of
data
or i nformati on from
the
data
buffers
to
a memory
unit,
provides a write
key, and increments (or decrements, if Read Backward
",,.,.10,.'
+ho
mom",r"
h.,+o
,..",1,.1roc:"
nn,.l
,.Iorromon+c:
+ho
_._-'J
...
-
...
_
...
_.,
-,.-
--_._-- -
..
- --_._
...
_
..
--
----
byte
count
by one for
each
byte transferred
out
of
the
data
buffers.
The write key is
evaluated
against
the
preassigned
write
lock for the memory word
location
accessed.
If
the
write
key is
valid
for
each
memory word
loca-
tion accessed, the input operation continues, as
des-
cribed
above,
unti I
it
is completed or terminated
by an "unusual end" condition,
other
than Write Lock
Violation. If the write key
is
not
valid,
the memory
unit
(1)
generates
and transmits a Write Lock
Viola-
tion
(WLV)
signal to the
lOP,
(2)
rejects
the new
data,
and
(3)
does not disturb the previous contents of
the
memory word location accessed.
If
the write key is invalid for
any
memory word location
accessed and the
HTE
flag
is
coded as a
1,
the input
operation is terminated immediately upon
receipt
of
a
WLV
signal (see "Termination Phase
ll
).
If
the
HTE
flag
is
coded as a
0,
the
memory unit may
accept
or
reject
the
data
or
information, based on
the
write
key/write
lock
evaluation
for
each
memory word
location accessed, without
affecting
the operations
within the lOP,
device
controller, or
device.
The
input
operation
continues unti I
either
completed or
terminated by an
"unusual end" condition, other than
a Write Lock Violation.
I/O
Operation
Phases 149
