3.
Diagnostic
logic.
Each memory
driver
module
carries
logic
used
exclusively
for
localizing
faulty
elements
in
that
module.
The
benefit
derived
from
this
diagnos-
tic
logic depends on such
external
factors
as
the
ac-
cessibility
to a module
tester.
Memory system performance depends on these factors:
1.
Access time
of
memory
unit.
2.
Cycle
time
of
memory
unit.
3.
Type of
cycle
requested.
4.
Number of memory
units.
5.
Interleaving.
6 • Type
of
port (fast or norma
I)
selected.
7.
Self
or mutual
interference
between
memory
requests.
All these factors
characterize
not
only memory
performance
but a Iso system
performance.
Port
access
time
and
cycle
time
are
essential memory
speed
characteristics
pertaining
to
CMM
operations.
1.
Port
access
time.
This
is
the
time interval measured
between
the
clock
pulse
that
transmits
an
address word
from
the
Memory
Interface
(MI)
to
an
idle
memory
unit
and
the
clock
pulse
that
translates
a memory word from
the
same memory
unit
to
the
MI.
2.
Cycle
time.
Cycle
time
depends
on
the
operation
be-
ing performed
and
on
the
sequence
of
operation.
Cycle
time determines
the
maximum
rate
at
which a memory
unit
can
accept
requests.
VIRTUAL
AND
REAL
MEMORY
Virtual memory
is
the
address
space
available
to
an
in-
dividual
program. The maximum
size
of
virtual memory is
128K words, broken into as many as 256 pages
of
512 words
each
distributed
throughout
the
available
pages
of
real
memory.
Real memory corresponds
to
the
physical memory,
and
its
size
is
equal
to
the
total number
of
words
contained
within
all
memory units in the system. The
size
of
real memory ranges
from a minimum
of
16K words to a maximum of 256K words.
Note:
Real memory address
space
is
1
mi
Ilion words.
MEMORY
REFERENCE
ADDRESS
Memory locations 0 through
15
are
not
normally
accessible
to
the
programmer
because
their
memory addresses
are
re-
served as register designators for
"register-te-register"
op-
erations.
Nevertheless
an
instruction
treats
any
of
the
first
16
registers of
the
current
register
block
as if
it
were
a
location
in
main memory. Furthermore,
the
register
block
can
hold
an
instruction
(or a series
of
as
many as
16
instruc-
tions) for
execution
just as though
the
instruction (or
instruc-
tions)
were
in main memory.
The following terms
are
used in
the
various types
of
address-
ing
described
in
subsequent
sections.
See
also
Figure
5,
which
illustrates
the
control
and
data
flow during address
generation.
1.
Instruction Address. This
is
the
address
of
the
next
instruction
to
be
executed.
For
real,
real-extended,
and
virtual
addressing
the
17-bit
instruction address is
contained
within
bits
15-31
of
the
program
status
words
(PSWs)
•
2. Reference Address.
Th
is is
the
17
-b
i t or
20-b
it
address
associated
with
any
instruction
(except
that
in a trap
or
interrupt
location
that
has a 0 in
bit
position
10).
For
real,
real
extended,
direct,
and
virtual
addressing,
the
reference
address is
the
address
contained
within
bits 15-31
of
the
instruction
itself.
The
reference
address may
be
modified by using
indirect
addressing,
indexing,
and
memory
mapping.
A
refer-
ence
address becomes
an
effective
virtual
address
after
the
indirect
addressing
and/or
postindexing (if
re-
quired)
is
performed.
3.
20-Bit
Trap or
Interrupt
Reference Address.
If
bit
posi-
tion
10
of
any
instruction in a trap
or
interrupt
location
contains
a
0,
bits 12-31
of
that
instruction
are
used as
a
20-b
it
reference
address.
Th
is
20-b
i t
reference
ad-
dress
can
be
modified only by using
indirect
address-
ing.
This
20-bit
reference
address
cannot
be
indexed
or
mapped.
(See
"Interrupt
and
Trap Entry Addressing",
later
in this
chapter.)
4.
Direct
Reference Address.
If
neither
indirect
address-
ing nor indexing
is
called
for
by
the
instruction
(i.
e.,
if
bit
0
and
the
X
field
contain
zero),
the
reference
address
of
the
instruction
(as
defined
above)
becomes
the
effective
virtual
address.
Direct
addressing may
be
used during
real,
virtual,
or real
extended
address-
ing modes,
including
trap
and
interrupt
operations.
Di-
rect
addressing during
virtual
addressing does not
pre-
clude
memory
mapping.
5.
Indirect
Reference Address. The
7-bit
operation
code
field
of
the
instruction
word format provides for as many
as 128 instruction
operation
codes,
nearly
all
of
which
can
use
indirect
addressing
(except
immediate-operand
and
byte-string
instructions).
If
the
instruction
calls
for
indirect
addressing (bit position 0
contains
a 1),
the
reference
address (as
defined
above)
is
used
to
access
a
word
location
that
contains
the
direct
reference
address
in
bit
positions
15-31,
or
bit
positions 12-31 for
certain
real
extended
addressing
operations.
The
indirect
ad-
dressing
operation
is
limited to one
level,
regardless
of
the
contents
of
the
word
location
pointed
to by
the
ref-
erence
address
field
of
the
instruction.
Indirect
ad-
dressing occurs
before
indexing;
that
is,
the
17-bit
Main
Memory 17
