4-14 Phaser 3140/3155/3160 Printer Service Manual
General Troubleshooting
5 Check and reseat the wiring harness
between the Power Supply CON2 and
Controller Board CN5 (CN7 on model
3160).
Is the wiring harness damaged?
Repair the
harness.
If the
problem
persists, go
to step 6
Go to step 6.
6 Check and reseat the wiring harness
between Control Panel CN1 and
Controller Board CN8 (CN9 on model
3160).
Is the wiring harness damaged?
Repair the
harness.
If the
problem
persists, go
to step 7.
Replace the
Controller
Board
(page 8-51).
If the
problem
persists, go
to step 7.
7 Replace the Control Panel (page 8-51). Complete.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
