8-4 Phaser 3140/3155/3160 Printer Service Manual
Service Parts Disassembly
Notations in the Disassembly Text
• The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
•The notation “PLX.X.X” indicates that this component is listed in the Parts List.
• Bold arrows in an illustration show direction of movement when removing or
replacing a component.
• The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Provides information specific to the replacement of parts or assemblies.
