Xerox Phaser 3160B Service Manual

4-12 Phaser 3140/3155/3160 Printer Service Manual
General Troubleshooting
Power Supply Troubleshooting
Warning
Hazardous voltage is connected to the wall outlet.
AC Power Troubleshooting
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Power Supply, PL1.0.1 ■ Map 4 - 110V and 220V Power Supply
Boards
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the voltage at the AC wall outlet.
Is there approximately 110 VAC (or
220 VAC if the printer is a 220 V
configuration) at the AC wall outlet?
Go to step 2. Notify the
customer of
improper AC
output from
the outlet.
2 Check the power cord for defects or loose
connection.
Is the Power Cord loose or defective?
Replace or
reconnect
the Power
Cord.
Replace the
Power
Supply
(page 8-54).
