Phaser 3140/3155/3160 Printer Service Manual 9-3
Parts List
Example
UXB461515: Xerox Serial Number
UXB: Product Code for the Phaser 3160N, 220V printer
461515 = Serial Number for 3160N
Using the Parts List
• ID No.: The callout number from the exploded part diagram.
• Name/Description: The name of the part to be ordered and the number of
parts supplied per order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
• A black triangle preceding a number followed by a parenthetical statement in
an illustrated parts list means the item is a parent assembly, made up of the
individual parts called out in parentheses.
•The notation “with X~Y” following a part name indicates an assembly that is
made up of components X through Y. For example, “1 (with 2~4)” means part
1 consists of part 2, part 3, and part 4.
• An asterisk (*) following a part name indicates the page contains a note about
this part.
• The notation (NS) next to a part indicates that particular part is not spared,
but contained in a kit or major assembly.
•The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2
is attached to the other end that is plugged into P2.
Only parts showing part numbers are available for ordering by support. Parts
not showing part numbers are available on the parent assembly.
Abbreviations
Abbreviation Meaning
CC-ring
EE-ring
KL K-clip
SScrew
