3-22 Phaser 3140/3155/3160 Printer Service Manual
Error Messages and Codes
Fuser Gear Damaged from Overheating
There is a repetitive jam at the Fuser, or the Fuser rollers are not turning.
Warning
Allow the Fuser to cool before beginning the procedure.
Initial Actions
• Ensure that the Fuser is secured to the printer.
• Cycle printer power.
• If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Fuser Lamp, PL9.0.13
■ Fuser, PL9.0
■ Power Supply, PL1.0.1
■ Controller Board, PL1.0.2
■ Map 1 - Controller Board (3140)
■ Map 2 - Controller Board (3155)
■ Map 3 - Controller Board (3160B/
3160N)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Fuser Lamp for damage or
overheating.
Is the Fuser Lamp damaged?
Replace the
Fuser Lamp
(page 8-15).
Go to step 2.
2 Replace the Fuser (page 8-11).
Does the problem persist?
Go to step 3. Complete.
3 Replace the Power Supply
(page 8-54).
Does the problem persist?
Go to step 4. Complete.
4 Reseat connections on the Controller
Board.
Does the problem persist?
Replace the
Controller
Board
(page 8-51).
Complete.
