10-10 Phaser 3140/3155/3160 Printer Service Manual
Wiring
Map 6 - Motor, Solenoids, and Fan
s3160-114
Fan
Motor
Manual Feed Solenoid
Pick Up Solenoid
A
132
133
134
135
136
137
138
139
140
141
142
143
144
145
131
BCDEFGHI J KL
