Phaser 3140/3155/3160 Printer Service Manual 9-21

Parts List

Parts List 7.0 Drive Assembly (Model 3140)

ID No. Name/Description Part Number

0. Drive Assembly 030N00771

1. Bracket Gear —

2. Step Motor —

3. Impeller —

4. Step Motor Bracket —

5. Gear RDCN OPC —

6. Gear RDCN 57/18 —

7. Gear RDCN 90/31 —

8. Gear RDCN 103/41 —

9. Gear DRV Fuser Out —

10. Gear Hub Clutch —

11. Gear DRV Fuser In —

12. Screw-Taptype —

13. Plain Washer —

14. Motor BLDC —
