Phaser 3140/3155/3160 Printer Service Manual 9-31
Parts List
Parts List 10.0 Paper Tray Assembly
ID No. Description Part Number
0. Paper Tray 050N00547
1. Tray Frame —
2. Guide-Extension CST —
3. PMO Extension Small —
4. Adjust-M Cassette-R —
5. Adjust-M Cassette-L —
6. RPR-Pad Tray —
7. Plate-P-Knock Up —
8. Cam-M-Knock Up —
9. Screw-Taptype —
10. Spring-CS —
11.
11-1.
11-2.
11-3.
Tray Holder Pad Assembly
Sheet-Holder Pad
Friction Pad
Holder Pad
019N00998
—
—
—
12. Holder Pad Housing —
13. Spring ETC-Exit Roll FD —
14. Roller-M-Idle Feed —
15. Spring-ES —
16. Tray Cover —
17. Screw-Taptype —
18. Gear-Pinion —
19. Screw-Taptype —
20. PMO-Plate Locker —
21. Spring ETC-Locker, Plate —
22. PMO-Roller Upper DP —
