Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-26
Monitor Test Parameter Table
Chain Link Component
010 001 Fusing Relay
041 001 Low Voltage Power Supply 24V
042 001 Main Fan (Normal)
042 002 Main Fan (Half)
061 001 ROS Motor
071 001 Main Motor (Normal)
071 002 Main Motor (Half)
071 004 Paper Transport Motor (Normal)
071 005 Paper Transport Motor (Half)
071 007 Bypass Tray Feed Solenoid
071 008 Tray1 Feed Clutch
071 009 Take Away2 Clutch
071 010 Regi Clutch
071 011 Exit Clutch
071 012 Exit Clutch2
071 013 Duplex Clutch
071 014 Option Feeder1 Motor (Normal)
071 015 Option Feeder1 Motor (Half)
071 017 Option Feeder2 Motor (Normal) (not in use)
071 018 Option Feeder2 Motor (Half) (not in use)
071 020 Option Feeder1 Feed Clutch
071 021 Option Feeder2 Feed Clutch (not in use)
071 022 Option Feeder1 Take Away Clutch
071 023 Option Feeder2 Take Away Clutch (not in use)
093 001 Developer Motor (Normal)
093 002 Developer Motor (Half)
093 004 Yellow Toner Dispense Motor (Normal)
093 005 Yellow Toner Dispense Motor (Half)
093 006 Magenta Toner Dispense Motor (Normal)
093 007 Magenta Toner Dispense Motor (Half)
