Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-27
Monitor Test Example
This section explains Digital Output Testing using [071-002: Main Motor (Half)] and [071-010: Regi
Clutch] as an example.
1. Enter Service Mode. See “How To Enter Service Mode” on page 2-8.
2. Confirm that the [Printer Diag] is selected, and then press the OK button.
3. Use the [ ] button to select [Engine Diag], and press the OK button.
4. Use the [ ] button to select [Monitor Test], and press the OK button.
5. To set LVPS 24V to On, use the [ ] or [ ] button and select [041-001]
.
6. Press the OK button, and check the operation sound
.
7. To carry on checking the operation of Main Motor (Half), do not press the Back button. Use the
[ ] or [ ] button to display [071-002].
8. Press the OK button, and check the operation sound.
Note: Press the Back button to stop the test.
9. To carry on checking the operation of Regi Clutch, do not press the Back button. Use the [ ] or
[ ] button to display [071-010].
093 008 Cyan Toner Dispense Motor (Normal)
093 009 Cyan Toner Dispense Motor (Half)
093 010 Black Toner Dispense Motor (Normal)
093 011 Black Toner Dispense Motor (Half)
Monitor Test Parameter Table
Chain Link Component
Printer Diag
Engine Diag
Engine Diag
Monitor Test
Engine Diag
Monitor Test
Monitor Test
010-001 READY
Monitor Test
041-001 READY
Monitor Test
041-001 EXEC
Monitor Test
071-002 EXEC
Monitor Test
071-002 EXEC
To Next Page
