Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-30
NVM Saving (SaveNVM to ESS)
SaveNVM to ESS allows you to save the IOT NVM information to ESS.
Procedure
1. Enter Service Mode to select [Engine Diag] > [NVM Settings], and press the OK button.
See “How To Enter Service Mode” on page 2-8.
2. Use the [ ] button to select [SaveNVM to ESS], and press the OK button.
3. Press the OK button.
4. Press the OK button to return to the [Printer Diag] screen, and then exit Service Mode. See “How to
Exit Service Mode” on page 2-10.
NVM Loading (Load NVM from ESS)
Initialize Slave allows you to load all NVM information saved in ESS to the IOT NVM.
CAUTION: Do not execute "NVM Loading" unless "NVM Saving" has been executed. Doing so will
damage PWBA MCU.
Procedure
1. Enter Service Mode to select [Engine Diag] > [NVM Settings], and press the OK button.
See “How To Enter Service Mode” on page 2-8.
2. Use the [ ] button to select [Load NVM from ESS], and press the OK button.
3. Press the OK button.
4. Press the Back button to return to the [Printer Diag] screen, and then exit Service Mode.
See “How to Exit Service Mode” on page 2-10.
Engine Diag
NVM Settings
NVM Settings
Edit NVM
NVM Settings
SaveNVM to ESS
SaveNVM to ESS
OK?
SaveNVM to ESS
Processing
SaveNVM to ESS
Saved
Engine Diag
NVM Settings
NVM Settings
Edit NVM
NVM Settings
Load NVM from ESS
Load NVM from ESS
OK?
Load NVM from ESS
Processing
Load NVM from ESS
Loaded
