Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-56
Fax Memory Test
Fax Memory Test allows you to check the read and write ability of the Fax memory.
I/F Test
I/F Test provides the communication test between Fax Card, AFE Serial I/F, and IIT.
ASIC Test
Provides the ASIC built-in IJAC and JBIG tests.
Display After Diag
Note
Normal Error
CHECK OK *** Test Check NG ***: Displays the name of the test ended in error.
(Fax Flash W/R / SRAM W/R)
Display After Diag
Note
Normal Error
CHECK OK *** Test Check NG ***: Displays the name of the test ended in error.
(Fax Card I/F / AFE Serial I/F / IIT I/F)
Display After Diag
Note
Normal Error
CHECK OK *** Test Check NG ***: Displays the name of the test ended in error.
(ASIC IJAC / ASIC JBIG)
