Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-57
Relay/Signal Test
Item Range Description
Relay Test Relay Toggle Test 0150 - 9999 Toggles the Relay signal within the specified
frequency.
Relay Set Test ON, OFF Outputs the Relay signal at a specified level.
Hook Test Hook Toggle Test 0150 - 9999 Toggles the Hook signal within the specified
frequency.
Hook Set Test ON, OFF Outputs the Hook signal at a specified level.
Single Tone Send 0Hz - Continuously sends the selected frequency tone.
400Hz
462Hz
1080Hz
1100Hz
1300Hz
1500Hz
1650Hz
1850Hz
2100Hz
500Hz
600Hz
900Hz
1000Hz
DTMF Send DTMF
Continuous
0 - 9, A - D, *, # Continuously sends the DTMF signal.
DTMF
Individually
16 digits
(each digit 0 - 9,
A - D, *, #)
Sends the multiple digits DTMF signal.
Dial Pulse Send DP10
Individually
10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (10pps)
signal.
DP20
Individually
10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (20pps)
signal.
Ring Back Tone - Sends the ringback tone.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
