Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-63
Test Pattern
Specifies the test pattern and the parameter value of the test.
IIT I/O Check
Checks the IIT I/O components operation.
Item Range
Pattern No. 3 digits (each digit 0 - 9)
Pt07:Step Cycle 4 digits (hexadecimal)
(each digit 0 - 9, A - F)
Pt08:Step Cycle
Item Sensor Status
Home Pos Sensor ON or OFF
Tray Sensor
Feed Sensor
DADF Cover Sensor
DADF Duplex Sensor
Item
Display After Diag
Description
Normal Error
Lamp.. Set ON Check OK - The lamp is set to ON.
Set OFF The lamp is set to OFF.
FB Motor Forward Now Driving Check NG Turns the FB Motor to the forward direction.
Reverse Turns the FB Motor to the reverse direction.
DADF Motor Forward Now Driving Check NG Turns the DADF Motor to the forward
direction.
Reverse Turns the DADF Motor to the reverse
direction.
DADF
Solenoid
Set ON Check OK - The DADF Solenoid is set to ON.
Set OFF The DADF Solenoid is set to OFF.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
