Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-69
950 103 IMAGE_PARAM_THROUGH1 Image Quality
Parameter
Through Setting
1
0bit0 0: ENL
Conversion
bit1 1: RGB 3x9 Filter
bit2 2:
Enlarge/Reduce
bit3 3: 3x9 Color
Conversion
bit4 4: Background
Suppression
bit5 5: NSP
bit6 6: NSP
(Saturation
Conversion Factor)
bit7 7: Color
Adjustment (Linear
Conversion)
950 104 IMAGE_PARAM_THROUGH2 Image Quality
Parameter
Through Setting
2
0-255 0 Continued from
"Image Quality
Parameter Through
Setting 1"
bit0 8: Color
Adjustment (L*
INLUT)
bit1 9: 4-Color DLUT
Color Conversion
bit2 10: 3-Color DLUT
Color Conversion
bit3 11: JPEG
Compression
bit4 12: K 5x5 Filter
bit5 13: Resolution
Conversion
bit6 14: Delete Border
bit7 15: TRC
950 105 IMAGE_PARAM_THROUGH3 Image Quality
Parameter
Through Setting
3
0-255 0 Continued from
"Image Quality
Parameter Through
Setting 1, 2"
bit7 16 - 23: Reserve
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
