Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-70
950 106 IMAGE_PARAM_THROUGH4 Image Quality
Parameter
Through Setting
4
0-255 0 Continued from
"Image Quality
Parameter Through
Setting 1, 2, 3"
bit7 24 - 31: Reserve
950 107 DIAG_IMG_PATH Select Test
Pattern
0-255 0 0 = Normal
Operation
1 = Raw Image
Output 1
2 = Raw Image
Output 2
3 = 1 Dot Grid
Output
4 = Vertical
Gradation Output
5 = Horizontal
Gradation Output
6 = Solid Color
Output
7 = Lamp On Silent
Image Output
8 = Lamp Off Silent
Image Output
9 = Shading Memory
Silent Image Output
10 = FXIF Test
11 = Patch Pattern
12 = AFE: Maximum
Transient Status
13 = AFE: Lamp
14 = AFE: Fixed
Data?Output
950 108 DIAG_IMG03_GRID_SIZE Test Pattern 3
Parameter
0-1023 200 1 Dot Grid Size
950 109 DIAG_IMG04_GRADATION Test Pattern 4
Parameter
1-255 10 Vertical Gradation
Step
950 110 DIAG_IMG05_GRADATION Test Pattern 5
Parameter
1-255 10 Horizontal Gradation
Step
950 111 DIAG_IMG06_R_LV Test Pattern 6
Parameter R
0-255 128 Image Path R Level
950 112 DIAG_IMG06_G_LV Test Pattern 6
Parameter G
0-255 128 Image Path G Level
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note
To Next Page
