Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-80
825 201 DIAG_NCU_COUNTRY_RELAY NCU Country
Setting - Relay
Setting
0,1
825 202 DIAG_DAA_REG732 FastEdgePulseDia
l2
0,2
825 203 DIAG_DAA_REG_EMI DAA SSD Register
0x02 Setting
0-255
825 601 DIAG_LINE_MONITOR_ENABLE Line Monitor
Setting
0,1
825 604 DIAG_CED_DETECT_TIMER CED Detect Time 25-255
825 666 DIAG_MANUAL_CNG_SIGNAL Manual Send
CNG
Transmission
0,1
825 605 DIAG_CNG_STOP_SELECT CNG
Transmission
Stop Judge
Selection
0,2
825 608 DIAG_RTN_TX_RATE RTN Command
Transmission
Standard (Rate)
0-100
825 609 DIAG_RTN_TX_LINE RTN Command
Transmission
Standard (Serial
Line Number)
0-255
825 610 DIAG_G3M_CALL_T1_TIMER T1 Timer Value
Soon After
Calling
0-255
825 611 DIAG_G3M_TX_T1_TIMER T1 Timer Value
Upon Sending
0-255
825 612 DIAG_G3M_RX_T1_TIMER T1 Timer Value
Upon Receiving
0-255
825 613 DIAG_G3M_T2_TIMER T2 Timer Value 0-255
825 614 DIAG_G3M_T3_TIMER T3 Timer Value 0-255
825 615 DIAG_G3M_AUTO_T4_TIMER Auto
Send/Receive T4
Timer Value
0-255
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
