Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-81
825 616 DIAG_G3M_MAN_T4_TIMER Manual
Send/Receive T4
Timer Value
0-255
825 617 DIAG_G3M_IVL_TIMER Silent Time Timer
Value
0-255
825 618 DIAG_G3M_FSK_CHK_TIMER FSK Observation
Timer Value
0-255
825 619 DIAG_ITUT_PIX_DELAY Image
Information Send
Delay Time
0-255
825 620 DIAG_G3M_DROP_OUT_TIMER Image
Information
Receive Dropout
Observation
Timer Value
0-255
825 621 DIAG_G3M_NSF_DIS_TIME NSF/DIS
Transmission
Time
0-3
825 622 DIAG_G3M_TX_MODEM_SPEED Communication
Mode Upon
Sending (Speed)
0-5
825 623 DIAG_G3M_RX_MODEM_SPEED Communication
Mode Upon
Receiving (Speed)
0-5
825 625 DIAG_G3M_DIS_IGNORE_NODIS Ignore Times0-255
825 626 DIAG_G3M_TSI_CIG_MODE TSI/CIG Send
Timing
0-2
825 627 DIAG_G3M_WITH_CSI CSI Send 0,1
825 628 DIAG_G3M_FTT_FALLBACK Number of FTT
Until Fallback
0-2
825 629 DIAG_G3M_TCF_CHECK TCF Signal Judge
Standard
0,1
825 630 DIAG_G3M_TX_CABLE_EQU Send Cable
Equalizer
0-3
825 631 DIAG_G3M_RX_CABLE_EQU Receive Cable
Equalizer
0-4
825 632 DIAG_G3M_TAP_HOLD TAP HOLD 0,1
825 633 DIAG_G3M_V29_EPT EP Tone 0,1
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
