Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-126
024 340 IOT Firmware
Error
Detect Firmware Error Engine Controller Error 024-340
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Code:xxxxxxxxh
Page 2-178
024 360 MCU DownLoad
Error
MCU-F/W download
failure
Engine Code DownLoad
Error 024-360
Power Off/On Printer and
Send Firmware Data again.
-
024 362 IOT Start Image
Marking Timeout
IOT internal error. Print Engine Start Error 024-362
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-190
024 371 IOT-ESS
Communication
Fail
Communication fail
between IOT and ESS.
Engine Communication Error 024-
371
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
024 920 <IOT Standard
Stacker Full>
Center Tray Full is
Detected.
Output Tray Full
Remove Paper from Output Tray.
Page 2-190
024 927 Mono only mode
reached Limit
Mono only mode(plural
color toners are empty)
reached Limit
Multiple Toner Cartridges Empty
Open the Front Cover.
Then, replace Toner Cartridges.
Replace
To ne r
Cartridges.
024 947
948
Tray Detached Tray 1 : 947
Tray 2 : 948
Tray N Missing 024-xxx
Insert Tray N.
Insert the
tray.
026 720 USB Memory Full Writing to USB memory
failed.
USB Memory Full 026-720
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
026 721 USB Memory
Write Error
Writing to USB memory
failed.
USB Memory Write Error 026-721
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
027 446 IPv6 duplicate At start-up, detect
duplicate IPv6 address on
network.
XXXXXXXXXXXXXXXX
Duplicate IPv6 Addr, Reconfigure
Replace the
IP Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
