Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-187
093-925 SFP / 093-953 MFP IOT X CRUM Error (K Toner)
093-980 IOT Y Toner Type Error
093-960 IOT X CRUM ID Error (Y Toner)
Step Check Yes No
Possible causative parts:
• Black Toner Cartridge (PL5.1.11)
• Dispenser Assembly K (PL5.1.7)
• Top Harness Assembly (PL18.2.5)
• MCU Board (PL18.1.13)
1 Check the Toner Cartridge installation
Is the connection part between the CRUM and the Dispenser
Assembly K inside the Black Toner Cartridge clean (without
any foreign objects)?
And, is the Black Toner Cartridge installed properly?
Go to step 2. Reinstall the
Black Toner
Cartridge.
2 Check the CRUM of the Toner Cartridge
Is the connection terminal of the CRUM inside the Black
Toner Cartridge broken?
Replace the Black
Toner Cartridge.
Go to step 3.
3 Check the Dispenser Assembly K
Is the connection terminal of the Dispenser Assembly K
broken?
Replace the
Dispenser
Assembly K.
Go to step 4.
4 Check the Dispenser Assembly K connection
Check the connection between the Dispenser Assembly K
and the MCU Board.
Are P/J194 and P/J19 connected securely?
Go to step 5. Connect P/J194
and P/J19
securely.
5 Check the continuity between the Dispenser Assembly Y and
the MCU Board
Is each cable of P/J194<=>P/J19 continuous?
Replace the MCU
Board.
Replace the Top
Harness
Assembly.
Step Check Yes No
Possible causative parts:
• Yellow Toner Cartridge (PL5.1.8)
1 Check the Toner Cartridge installation
Is a Toner Cartridge other than a Yellow Toner Cartridge
installed?
Or, is the installed Toner Cartridge for another printer?
Install the right
Yellow Toner
Cartridge.
Reinstall the
Yellow Toner
Cartridge.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
