Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-188
093-981 IOT M Toner Type Error
093-961 IOT X CRUM ID Error (M Toner)
093-982 IOT C Toner Type Error
093-962 IOT X CRUM ID Error (C Toner)
093-928 IOT K Toner Type Error
093-926 IOT X CRUM ID Error (K Toner)
Step Check Yes No
Possible causative parts:
• Magenta Toner Cartridge (PL5.1.9)
1 Check the Toner Cartridge installation
Is a Toner Cartridge other than a Magenta Toner Cartridge
installed?
Or, is the installed Toner Cartridge for another printer?
Install the right
Magenta Toner
Cartridge.
Reinstall the
Magenta Toner
Cartridge.
Step Check Yes No
Possible causative parts:
• Cyan Toner Cartridge (PL5.1.10)
1 Check the Toner Cartridge installation
Is a Toner Cartridge other than a Cyan Toner Cartridge
installed?
Or, is the installed Toner Cartridge for another printer?
Install the right
Cyan Toner
Cartridge.
Reinstall the
Cyan Toner
Cartridge.
Step Check Yes No
Possible causative parts:
• Black Toner Cartridge (PL5.1.11)
1 Check the Toner Cartridge installation
Is a Toner Cartridge other than a Black Toner Cartridge
installed?
Or, is the installed Toner Cartridge for another printer?
Install the right
Black Toner
Cartridge.
Reinstall the
Black Toner
Cartridge.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
